MTP40S is an extremely small and light pocket transmitter especially designed for professional wireless microphone applications. Very easy and quick to use thanks to OLED display, dedicated buttons and a joggle selector.

It benefits of the LINEAR feature @L20 power setting: allows EVENLY SPACED frequency allocation intermodulation free

FEATURES

• Up to 232 MHz bandwidth in 470/1160 MHz range
• Input dynamic extension with an integrated HW limiter (30 dB above peak)
• Enhanced robustness against self-interferences and antenna performances thru a proprietary “intermodulation cancellation” circuit
• LINEAR feature @L20 power setting: allows EVENLY SPACED frequency allocation intermodulation free
• Miniature design with flexible pcb (no connectors) for extended reliability
• Ultra-light metal alloy body (80g without batteries)
• User selectable multi-companding systems:
  ENR (noise optimized)
  ENC (voice optimized)
• Battery: 2 AA Alkaline, rechargeable NiMH or Lithium
• Autonomy:
  approx. 7h @ 100mW and 20L(=20mW LINEAR)
  approx. 10h @ 50mW
  approx. 12h @ 20mW
  approx. 14h @ 10mW
• Infrared interface for management and firmware update
• Easy and quick to setup thru an Oled display gain/freq button and a joggle selector
• Extended regulation on Mic input gain
• Max input level 26dBu (15.5 V clipping) to connect directly to mixers and instruments
• 48V phantom power to use wired mic thru the PHA48 accessory
