P+S TECHNIK Cooke S2 / S3 Panchro Lenses (18mm, 25mm, 32mm, 40mm, 50mm, 75mm, 100mm)

9 500 Kč

Discount -30 %

6 650 Kčexcl. VAT / shooting day

8 047 Kč incl. VAT

P+S TECHNIK Cooke S2 / S3 Panchro Lenses (18mm, 25mm, 32mm, 40mm, 50mm, 75mm, 100mm)

Set of seven Cooke S2 / S3 lenses (18 / 25 / 32 / 40 / 50 / 75 / 100mm) set has two opposed scales, so focus and iris setting can be read from both sides of the camera, marked with whole stop markings. Both rings, iris and focus, are equipped with standard 0.8 gear module as is compatible with standard gear wheels for follow focus and lens control systems. The new front diameter of 80mm is standard mattebox interface.

Cooke Speed Panchro 18mm SIII T2.3
Cooke Speed Panchro 25mm SIII T2.3
Cooke Speed Panchro 32mm SII T2.3
Cooke Speed Panchro 40mm SII T2.3
Cooke Speed Panchro 50mm SII T2.3
Cooke Speed Panchro 75mm SII T2.3
Cooke Deep Field Panchro 100mm SII T2.8

9 500 Kč

Discount -30 %

6 650 Kčexcl. VAT / shooting day

8 047 Kč incl. VAT

Usual stock: 1 pcs
Pickup of equipment the night before is free
Option for insurance included in price and transport to location

Rental includes
7

1 × Cooke Speed Panchro 18mm SIII T2.3
1 × Cooke Speed Panchro 25mm SIII T2.3 (macro extended range / close focus)
1 × Cooke Speed Panchro 32mm SII T2.3 (macro extended range / close focus)
1 × Cooke Speed Panchro 40mm SII T2.3 (macro extended range / close focus)
1 × Cooke Speed Panchro 50mm SII T2.3 (macro extended range / close focus)
1 × Cooke Speed Panchro 75mm SII T2.3
1 × Cooke Deep Field Panchro 100mm SII T2.8 (macro extended range / close focus)

Specifications and parameters

Cooke Speed Panchros (T2.2 - 2.8) jsou velmi oblíbené pro svou originální a lety prověřenou beauty kresbu, která se složite duplikuje v dnešní době v postprodukci. Hollywoodská optika z 50-tých let rehousovaná od firmy P+S Technik. Ostřící i clonové kroužky jsou vybavené standardím 0.8mod ozubením. Pro kompendia mají všechny objektivy přední průměr 80mm.

Cooke Speed Panchro 18mm SIII T2.3
Cooke Speed Panchro 25mm SIII T2.3
Cooke Speed Panchro 32mm SII T2.3
Cooke Speed Panchro 40mm SII T2.3
Cooke Speed Panchro 50mm SII T2.3
Cooke Speed Panchro 75mm SII T2.3
Cooke Deep Field Panchro 100mm SII T2.8

	18 III	25 III	32 II/III	40 II	50 II	75 II	100 II
T-Stop Range	T 2.4 - 22	T 2.4 - 22	T 2.4 - 22	T 2.4 - 22	T 2.4 - 22	T 2.4 - 22	T 2.8 - 16
Angular Rotation Iris original Lens	60°-90°	60°-90°	60°-90°	60°-90°	60°-90°	60°-90°	60°-90°
Min. Marked Object Distance m / f	0,3 / 12 in	0,5 / 20 in	0,4 / 16 in	0,6 / 2 ft	0,9 / 3 ft	1,4 / 4.5 ft	1,2 / 4 ft
Close Focus from Lens Front	10cm	8cm	20cm	27cm	13cm	40cm	< 70cm
Angular Rotation to MOD Endstop	250°	250°	250°	250°	250°	250°	250°
Image Diagonal also review image circle charts	< 27mm	< 29mm	30mm	30mm	30mm	30mm	30mm
Length from Front of Lens to Lens Mount	51mm	52mm	50mm	52mm	76mm	76mm	125mm
Front Diameter	80mm	80mm	80mm	80mm	80mm	80mm	80mm
Total Weight	520 gr.	440 gr	390 gr	430 gr.	560 gr.	700 gr.	1150 gr.
Mount	Arriflex PL-Mount
Focus Scales	metric or footage scales - two opposing focus scales with hard stop
Markings	24
Focus Drive Gear	teeth 0,8 metric module industrial standard,with hard stop, 90 mm from image plane
Iris Scales	iris scales from Camera Operator side with hard stop
Iris Drive Gear	teeth 0,8 metric module industrial standard,hard stops, 70 mm from image plane

Brand	Cooke
Mount (coverage)	PL mount
Type of lenses	Sferický, Cine
Sensor Coverage	Super 35 res.
Widest lens in set	18 mm
Longest focal lenght in set	100 mm
Max lens speed (T)	2.3 t
Camera mount	PL mount
